Hydraulic Gears
Appiah Hydraulics is proud of its heritage, with millions of products installed around the world and product lines which are more than twenty eight years old.
In Hydraulic Gears section, we manufacture of ; Hydraulic Travel Gears, Swing Gear, Swing Drive, Winch Gear and any other special gear projects or new casting developments. Appiah Hydraulics has all tpye of Hydraulic Gear Development Dvision and we are able for any special projects. All Details below about Hydraulic Gears.
Hydraulic Gears
Appiah offers a wide selection of planetary gearboxes for the whole range of mobile applications.
We offer Torque output 9.5 to 450 kNm.
Description ; Planetary gearboxes are used as propel drives in tracked vehicles or as wheel drives in wheeled vehicles as well as swing drives for rotary motion and as winch drives for lifting and lowering loads.
More Details,
The planetary gearboxes have two, three or more planetary stages. They are available with a number of different Appiah hydraulic motor variants.
Travel Gears X
For travel drives in tracked and wheeled vehicles.
Also suitable for other rotary motion sequences, e.g. drum drives, milling drum drives etc.
Two-, three or four-stage planetary gearbox
For attachment of Appiah fixed or variable motors (M Motor ISO, M Motor Fixed Plug-in)
Torque output 9.5…450 kNm
Travel Gears X2000
Drive unit for tracked vehicles
Integrated hydraulic swash plate axial piston motor.
Two-stage planetary gearbox
Pressure sensitive 2-point motor adjustment (Automatic Shifting Function)
Torque output 13.5…42.5 kNm
Travel Gears X8000
For travel drives in tracked and wheeled vehicles
Two- or three-stage planetary gearbox
Can be combined with Appiah's extensive line of motors
Perfect matching of the gearbox ratio with the hydraulic motor
Torque output 10…130 kNm
Swing Gear
For the swing drive of the superstructure, e.g. of excavators, cranes, forestry machines, ship unloaders
For use in all applications where precise positioning is necessary
Two- or three-stage planetary gearbox
For attachment of Appiah fixed motors in space-saving plug-in design
Torque output 4…94.5 kNm
Swing Drive
Drive unit for swiveling of the superstructure, e.g. of excavators, cranes and drilling equipment
Two-stage planetary gearbox .
With attached axial piston fixed motor with swashplate design
Torque output 4…14.5 kNm
Winch Gear
For direct installation in winch drums, e.g. for crane applications
Two- or three-stage planetary gearbox
Rope pull force 50…684 kN
Torque output 9.5…325 kNm
